CP High Pressure Filter Pump For Centre Through Tool Coolant (35 To 70 Bar Pressure)

Description

High pressure application: Ideal for applications requiring high pressure - 35 to 70 bar with built-in double cyclone filter delivering 50 microns filtered coolant for CTS applications. Double cyclone giving enhanced filtration: The suction coolant enters the hydro-cyclone in the center, and the pre-filtered coolant enters the peripheral secondary hydro-cyclone of 6 numbers further filtering to 50 microns. High efficiency plunger: The 50 microns filtered coolant enters through plunger developing the pressure required for the application up to 35~70 bar with respect to 2.2 or 3.7kW motor respectively. Effective Sludge Separation: Contaminated coolant delivered from bottom of the pump is collected in the collection bin and the solid particles get settled down in the bin and clean coolant comes back to the coolant tank for recirculation.
