Intensive Care Bed (Manual) (Removable Polymer mould
  • Model No: VIB-6001
  • Category: Medical Surgical and Hospital Instruments and Equipment
  • Keywords: Intensive Care Bed
  • Manufacturer Name: VMS
  • Packing size: 1
  • Price: ₹50,917

Description

Overall approx dimension: 2240mm (L) x 1000 mm (W). Bed frame approx. dimension: 2080mm (L) x 910mm (W). Height adjustment approx. (without mattress): Minimum height 490mm to Maximum height 710mm. Backrest, upper leg , height and Trendelenburg / Reverse Trendelenburg adjustment on crank mechanism with separate screw mechanisms provided at leg end with stainless steel handles. Four section perforated mild steel CRCA sheet top. Framework made from mild steel ERW rectangular tubes. Mounted on four synthetic body castors 125mm wheel dia, two with brake and two without brake. Rubber buffers at four corners. Telescopic stainless steel IV pole with four locations at four corners of the bed. Pre-treated and powder coated finish. Supplied in knocked down condition.
