High Precision Levelling & Alignment Mounts Series DFL1-S3
- Model No: High Precision Levelling & Alignment Mounts Series DFL1-S3
- Category: Anti Vibration Mountings
- Keywords: Dynemech High Precision Levelling & Alignment Mounts Series DFL The DFL series mounts are made from a high grade casting body. Large supporting surface and high levelling adjustment is available. The slot in the middle allows placement of these mounts after the grouting bolts are fixed in the foundation. Suitable for VTL, long bedded CNC machines, large boring machines, plano miller etc.
- Manufacturer Name: Dynemech
- Packing size: Standard
- Price: ₹6,200
Description
Length:188(mm) Width:140(mm) Height:68.5(mm) Load Capacity: 12200 Kg Max. Torque Value (N.m):603 Adjustment Range(mm):6 4 Nos Weight ( Kg.): 45 kg Material: Cast Iron Colour: Green/Dark Grey 4 Nos of Box Size: 13"x8"x7 4 Nos of Boxes: 2 Delivery Time: 10-12 Days Price-6200
